eli workspace — overview & capability map

One codebase, two modes

• Local mode (ELI_MODE=local, the default — env.ts:15): a guest, no-account app on http://localhost:3737 (package.json → next dev --turbopack -p 3737). Your notes are plain markdown files in a vault directory you pick; everything else — FTS5 full-text index, wikilink graph, embeddings, versions — lives in a rebuildable per-vault SQLite database at ~/.eli/index/<hash>.db. Delete the index and eli rebuilds it from the files.
• SaaS mode (ELI_MODE=saas): a multi-tenant hosted product on Supabase — Postgres (+ tsvector, pgvector) with Row-Level Security as the security boundary (33 policies over 9 tables, pgTAP-verified in CI), magic-link/OAuth auth, workspaces with role-based memberships, comments, share links, and Realtime change notifications.

Both modes render the same RSC/component tree: route groups app/(local)/ and app/(saas)/ share components/* and app/_actions/*, and every surface talks to storage through the StorageAdapter interface (lib/storage/adapter.ts), resolved by getStorage() (lib/storage/index.ts:20). “Agent-native” is not a bolt-on: a 16-tool MCP server (lib/mcp/server.ts) is served over stdio (bin/eli-mcp.mjs) and streamable HTTP (app/api/mcp/[transport]/route.ts), agents that bypass MCP and edit .md files directly are picked up by a chokidar watcher and versioned with authorKind: 'agent', and an OpenAI-compatible /v1 facade (app/v1/) makes the vault a drop-in RAG backend for any OpenAI-SDK client.

The four invariants

Everything in this doc set hangs off four load-bearing invariants (docs/ARCHITECTURE.md §1):

1. The markdown file on disk (or body_md in Postgres) is the source of truth. FTS fragments, note_links, embeddings, the folder tree — all rebuildable derived index.
2. Every UI surface goes through getStorage(). No component, server action, API route, or MCP tool imports LocalAdapter or SupabaseAdapter directly (ADR-0004). Swapping modes is a config switch, not a refactor.
3. No raw HTML controls outside components/ui/* — all controls are shadcn/ui primitives, so theming, a11y, and keyboard handling stay uniform.
4. ~/.eli/config.json is the single user-scope state file (active vault, tokens, favourites, pairings). Vault contents never leak into it.

Phase status

Per the phase-file headers, docs/IMPLEMENTATION-LOG.md, and the git log (134 commits) — not the status table in docs/phases/README.md, which still claims Phases 2–7 are “not started” and is stale, as are parts of docs/ARCHITECTURE.md §11’s “not yet built” inventory. This doc set reflects code reality, cross-checked against the repo source at the current head (a8c4269).

Build health at the last log entry: 712 unit tests (+1 intentional skip), 25/25 Playwright e2e, 11 MCP harness tests, typecheck/lint/build green.

How to read this doc set

The Workspace tab is nine cluster pages plus one end-to-end journeys page, backed by the downloadable multi-page draw.io bundle. The central rule, applied uniformly:

Every subject gets BOTH a simplified view AND a detailed view, at BOTH the system (component/architecture) level AND the data-flow (runtime/sequence) level — and every cluster page explains how the subject works SEPARATELY (standalone) and TOGETHER (composed with the other clusters).

Concretely, each cluster page contains: System view — simplified (≤10-node component sketch), System view — detailed (full component map with file paths), Data-flow — simplified (the happy-path pipeline), Data-flow — detailed (sequence diagram with local-vs-SaaS branches and file:line anchors), plus a Standalone vs composed section. The draw.io bundle mirrors this: one page per cluster with labeled SIMPLIFIED and DETAILED bands, plus the four platform-level pages that correspond to the diagrams on this page. The journeys page replays three complete journeys (local-first solo loop, SaaS team loop, external-agent loop) across all clusters.

Cross-cutting surfaces that the multi-agent analysis treated separately — trash/bulk actions and the daily digest — are folded in where they live: storage modeling in core data & storage, the trash/bulk lifecycle in versioning & history, the digest builder in the AI platform, and the cron/prune machinery in platform ops.

Platform system view — simplified

The 10-second mental model: two kinds of principals (humans and agents), three kinds of surfaces (UI, MCP, HTTP APIs), one storage seam, two backends, one AI gateway.

Everything below elaborates this picture; nothing contradicts it. The one asymmetry worth memorising now: in local mode the .md file is written first (atomic tmp+rename) and the index catches up; in SaaS mode the write is a single transactional notes_save() RPC with optimistic concurrency on content_hash.

Platform system view — detailed

Each cluster’s 2–4 core components and every material cross-cluster edge. Colors encode cluster identity and are reused in the draw.io pages.

Notable structural facts this diagram encodes:

• C1 is the only cluster everyone depends on. ADR-0004 makes StorageAdapter the binding contract; a shared conformance suite (tests/adapter/contract.ts) must pass for every adapter.
• C5 and C4 never talk to each other’s tool registries. MCP tools (*_artifact naming) and AI-SDK chat tools (*_note naming, lib/ai/tools.ts) are deliberately parallel surfaces over the same storage (docs/tools.md:11-14).
• The save fan-out is where clusters compose: one updateNote() in C1 triggers C3 (embed queue), C6 (git queue), C9 (events bus → SSE), and — in SaaS — C7 (Realtime notification).
• C9’s SSE channel and C7’s Realtime toast are mode-twin mechanisms for the same UX outcome (other tabs/users see the change): in-process events bus locally, Supabase Realtime in SaaS.

Integration map — how the clusters compose

The clusters as nodes; every material runtime dependency as a labeled edge.

Running a cluster in isolation

The seams are real — meaningful sub-products fall out of subsets of clusters:

• C1 + C2 = a complete offline notes app. Vault picker, BlockNote editing, buckets/tags/folders, FTS search, version history — no network, no API keys, no git. This was literally Phase 1 as shipped.
• C1 + C5 = a headless agent vault. node bin/eli-mcp.mjs with VAULT_PATH boots a LocalAdapter directly — no Next.js server, no UI. An agent gets full CRUD, FTS search, versions, comments, and templates against plain files.
• C1 + C3 + C4 = a RAG service over a vault. Point any OpenAI-SDK client at /v1/chat/completions with a PAT and get hybrid-search-grounded answers; no eli UI involved.
• C1 + C7 = collaboration without AI. A team on Supabase gets workspaces, RLS-scoped notes, comments, invites, shares — no gateway key configured, AI routes simply unavailable.
• C6’s git layer and C9 are shed-able. ELI_DISABLE_GIT=1 turns the commit loop into a no-op (versions still recorded in C1’s versions table); ELI_DISABLE_LIVE_EVENTS=1 silences SSE (the e2e suite runs this way). The product degrades gracefully, never breaks.
• C8 standalone is thin by design — the clip handler, importers, and template engine are libraries over C1; the bookmarklet and PWA share-target are just alternative front doors.

The full loop

Composed, the clusters form one closed loop: content enters via C2 (typing), C8 (clip/share/import), or C5 (agent tools); C1 persists it file-first with a version row and fans out to C3 (embedding), C6 (git commit), and C9 (SSE/Realtime refresh); C3 makes it findable by keyword + meaning; C4 reads it back as RAG context for chat and digests, and can write back through the same storage seam (audited, attributed); C7 layers humans-in-the-loop on top (comments, shares, conflict snapshots); C6 guarantees any state is recoverable; and C9 keeps the whole thing observed, tested, and pruned. Every write — human, clipper, agent, or cron — is the same write: one StorageAdapter call, one authorKind-attributed version row, one fan-out.

Data-flow spine — simplified

The life of a note, compressed to one pipeline:

Data-flow spine — detailed

The full life of one note across all nine clusters, with local-vs-SaaS branches where the paths diverge.

Divergence summary — the spine is identical in shape in both modes; only four hops differ:

The diagrams on this page correspond to the four platform pages of the draw.io bundle — “Platform — System (Simplified)”, “Platform — System (Detailed)”, “Platform — Integration Map”, and “Platform — Data-Flow Spine”; per-cluster pages follow the same color coding. Download eli-workspace-architecture.drawio.
